You must lock the injection pump hub with its specific locking pin (e.g., Bosch tool # 0 986 680 030 or equivalent) before installing the gear/sprocket. The pump's internal timing is absolutely critical.
Failing to do this correctly will result in incorrect fuel injection timing, causing poor running, lack of power, or valves hitting pistons.
Replace the Timing Belt System: Since you must remove the timing belt to access the pump, it is mandatory to install a complete new timing belt kit (belt, tensioner, idler rollers). Reusing the old belt risks a later failure, which could destroy the engine.
Avoid Contamination:
DO NOT allow dirt to enter the pump's fuel ports. Use clean plugs/caps.
DO NOT turn or rotate the pump shaft by hand without the locking pin in place, as this can damage internal components.
Before final connection, prime the low-pressure fuel system to avoid the pump running dry.
Coding and Adaptation: After installation, you cannot simply start the engine. You must use a professional diagnostic tool (e.g., VCDS, ODIS) to:
Perform the "Fuel Delivery Valve Adaptation" (often in the ECU's basic settings). This calibrates the ECU to the new pump's flow characteristics.
Clear any stored fault codes.
Without this step, the engine may run poorly, with low power and high emissions.
Bolt Torque: All bolts, especially the pump mounting bolts and sprocket bolt, must be torqued to the exact specification in a specific sequence (typically in Newton meters, Nm). Over- or under-torquing can cause leaks, misalignment, or failure.
